The Analog Devices LTM46xx µ Module voltage regulator is a system in package (SiP) power management solution, available in a compact surface mount BGA or LGA package, featuring an integrated DC-DC controller, inductor, power transistor, compensation element, input and output capacitors. The LTM46xx µ Module regulator supports various functions such as step-down, step-up, and step-down step-up, and has multiple features. Some products are low EMI solutions that comply with EN55022 Class B standards, CISPR 22 (Class B), and CISPR 25 (Class 5). These µ Module power products adopt a compact and highly integrated design, which not only breaks through the limitations of time and space, but also provides highly reliable and efficient performance.

Characteristic

• Digital power system management

• Control and monitor switch regulators through PMBus/SMbus/I2C bus digital interfaces. It has the following control and monitoring functions:

  • Output voltage monitoring adjustment, sorting, and margin adjustment
  • Current monitor
  • Temperature monitor
  • Fault record
• Improved system reliability

  • Strictly control voltage accuracy
  • Remote debugging
  • Fault reporting and recording
  • Quick response to faults


• Voltage reduction boost

• The new product in the μModule voltage regulator series integrates magnetic components and can operate at higher input voltages.


  • High power, precision current sharing
• Parallel connection of several μ Module voltage regulators, evenly distributed load current provides high power to the load.


  • Ultra Low Noise
• This series of μModule voltage regulators is equipped with onboard filters, and the product meets the EN55022 Class B certification standard.
•
  • Tune-a-μModule voltage regulator
• Obtain internal compensation for the μModule regulator and adjust the loop response to achieve optimal output voltage accuracy, fast transient response, and minimum output capacitance, thereby powering FPGA, ASIC, and microprocessor.
•
  • Multiplex output
• 5. 4, 3 or 2 output μModule regulators support current sharing of outputs to increase load current, and can also control or sort each output on/off.
•
  • Ultra thin packaging

This series of μModule voltage regulators can be placed on the back of the PCB or next to FPGA or ASIC that share the same heat sink or cooling board.

Power module products mainly realize the localization replacement of LTM products. LTM can provide two types of packaging: BGA and LGA, supporting single and multiple power outputs with a wide output voltage range. Customized power modules can be realized according to user needs.
